7 65
Maintenance
Description Fuse rating Protected component
FUSE
DEDICATE DRL 10A BCM
BLOWER 2 10A A/C Control Module (Auto)
SENSOR 1 10A
Camshaft Position Sensor #1/#2, Oil Control Valve #1/#2, Canister Control Valve, A/Con Relay,
Immobilizer Module
SENSOR 2 10A C/Fan HI/Low Relay, Injector #1 ~ #4
IGN COIL 15A Ignition Coil #1 ~ #4, Condenser
ECU 3 20A PCM/ECM
SENSOR 3 15A
Oxygen Sensor (Up/Down), F/Pump Relay, Purge Control Solenoid Valve,
Variable Intake Solenoid Valve
H/LP LH 10A Head Lamp LH
H/LP RH 10A Head Lamp RH
HTD STRG 15A -
WIPER 10A PCM
B/UP LP (AP) 10A
Electro Chromic Mirror, Rear Combination Lamp LH/RH, Instrument Cluster,
A/V & Navigation Head Unit, Audio
MDPS 2 10A EPS Control Module
A/CON 10A A/Con Relay
