Peerless-AV SUA751PU - Sell Sheet - Manual

Ultra Slim Articulating Wall Arm
For 37" to 55" Ultra-thin Displays
*
This slim articulating mount transforms the viewing experience from ordinary to extraordinary.
Ultra-thin displays give the room a contemporary look, but only when married to an ultra-slim
mount that allows the maintenance of the ultra-thin aesthetic and still position the display at the
best viewing angle. Brilliant in its simplicity and ease of installation, the mount’s functionality is
optimized through its remarkable arm extension and swiveling hinge. Now you can create the
perfect viewing angle and truly achieve the ultra-thin experience at the same time.
EffortlEss
motion
One-Touch™ tilt allows
for ideal viewing
angles with ease
from nothing
to EvErything
Arm retracts to only 1.35"
(34mm) and extends up to
24.26" (616mm) from the wall
Display size: 37"-55" Max load: 100lb (45kg)
SUA751PU
 Universal mount fits
displays with mounting
hole patterns up to
825 x 439mm (32.48" x
17.27") and VESA ® 200 x
100, 200 x 200, 400 x 200,
400 x 400 and 800 x 400mm
compliant
 Arm retracts to only 1.35"
(34mm) and extends up to
24.26" (616mm) from the
wall
 +15/-5° of One-Touch™
tilt allows for ideal viewing
angles without the use of
tools
 Up to ±90° of side-to-side
swivel
 ±5° of roll offers a simple
way to horizontally level the
display post-installation
 Double stud wall plate
allows for perfect mount
placement
fEaturEs
* Designed exclusively for use with ultra-thin
displays 2” (51mm) deep or less
Flat against the wall Fully extended Improved tilt hinge
CliCK: peerless-av.com Call: 800.865.2112 faX: 800.359.6500
