Peerless-AV PLCM-1 - Installation - Manual

Installation and Assembly:
Straight Column Mount for 32" - 71" Flat Panel Screens
• Do not begin to install your Peerless product until you have read and understood the instructions and warnings
contained in this Installation Sheet. If you have any questions regarding any of the instructions or warnings, for US
customers please call Peerless customer care at 1-800-865-2112, for all international customers, please contact
your local distributor.
• This product should only be installed by someone of good mechanical aptitude, has experience with basic building
construction, and fully understands these instructions.
• Make sure that the supporting surface will safely support the combined load of the equipment and all attached
hardware and components.
• Never exceed the Maximum UL Load Capacity. See page one.
• If mounting to wood wall studs, make sure that mounting screws are anchored into the center of the studs. Use of
an "edge to edge" stud fi nder is highly recommended.
• Always use an assistant or mechanical lifting equipment to safely lift and position equipment.
• Tighten screws fi rmly, but do not overtighten. Overtightening can damage the items, greatly reducing their holding
power.
• This product is intended for indoor use only. Use of this product outdoors could lead to product failure and personal
injury.
WARNING
NOTE: Read entire instruction sheet before you start installation and assembly.
PLCM-1
PLCM-UNL
Model Max. Load Screen Size Range
PLCM-1 225 lb. (102.3 kg.) 32'' - 71''
PLCM-UNL 200 lb. (90.7 kg.) 32'' - 65''
ISSUED: 08-20-02 SHEET #: 200-9404-11 11-21-11
