Articulating Wall Mount
For 10" to 24" Displays
The SmartMountLT™ series articulating wall mounts give the ultimate in display positioning, with
one-person, Hook-and-Hang™ easy installation. The articulating arm allows you to extend the
display up to 14.58" (370mm) from the wall, and can retract to just 2.48" (63mm) from the wall.
The integrated cable management provides a clean, professional finish. One-Touch™ tilt of
±15°, ±5° roll for post-installation leveling and ±90° pivoting means the display will be perfectly
positioned for the optimum viewing angle.
Display size: 10"-24" Max load: 25lb (11kg)
SAL724
 Fits 10" to 24" displays, up to
25lb (11kg)
 Extends display 14.58"
(370mm) from the wall
 Retracts to hold display just
2.48" (63mm) from the wall
 ±90° of pivot allows for
perfect display positioning
 Quick and easy, Hook-
and-Hang™ one-person
installation
 Integrated cable
management provides
clean, professional
installation finish
 Easy leveling ±5° after display
installation
 Landscape or portrait
mounting options increases
display versatility
 Mounts to wood studs,
concrete, cinder block or
metal studs (metal stud
accessory required)
 VESA ® 75 and 100mm
compliant
 Installation hardware
included
 UL Listed
 Five-year warranty
FeatureS
CLICK: peerless-av.com CaLL: 800.865.2112 FaX: 800.359.6500
artICuLatING arm
Allows ±90° of pivot and
14.58" (370mm) of extension
from the wall
KeyhoLe deSIGN
Saves installation time
hooK-aNd-haNG™ SyStem
Offers easy, one-person
installation of the display
oNe-touCh™ tILt
Offers ±15° of viewing angle
adjustment
Arm retracts to just 2.48"
(63mm) and extends up to
14.58" (370mm) from the wall
±15° of viewing angle
adjustment
