Peerless-AV MDJ720 - Installation - Manual

ISSUED: 06-26-00 SHEET #: 139-9008-2 12-02-04
Visit the Peerless Web Site at www.peerlessindustries.com
1 of 5
For customer service call 1-800-729-0307 or 708-865-8870.
Additional models required
• †Ceiling Decoupler (DCT 600)
• Multi-Display Interface Bracket
(ACC 600)
• Fixed Length Extension Columns
• Jumbo 2000 mount (JM2640 ,
JM2650, or JM2660) or PLCM-2
plasma mount
Optional Accessories Kits
• Adjustable Extension Columns
(For more information call customer
service)
†Other ceiling decouplers may be used if mounted to
a structure other than an I-Beam (Call Customer
Service for more information).
Read instruction sheet before you start installation and assembly.
Multi-Display System for Jumbo 2000 ® Mounts ........................................................... pages 2-3
Multi-Display System for Plasma Mounts ................................................................. pages 2, 4-5
Models: MDJ 700,
MDJ 710, MDJ 720
Installation and Assembly - In-Line Multi-Display ™ Systems
MDJ 720
Maximum
Load Capacity
Model
MDJ 700
MDJ 710
1000 lb
(453.6 kg)
1200 lb
(544.3 kg)
1500 lb
(680.4 kg)
IN-LINE MULTI-DISPLAY ™ SYSTEM
FOR JUMBO 2000 ® MOUNTS
IN-LINE MULTI-DISPLAY SYSTEM FOR PLASMA MOUNTS
• Installer must verify that the ceiling will safely support
the combined weight of the Pipe, ACC 600, Extension
Columns, Jumbo/Plasma Mounts, Ceiling Decouplers,
and TVs/Plasmas.
WARNING
