Peerless-AV DS039 - Installation - Manual (Page 2)

ISSUED: 02-24-09 SHEET #: 090-9168-1
Visit the Peerless Web Site at www.peerlessmounts.com For customer care call 1-800-865-2112 or 708-865-8870.
2 of 5
PARTS LIST
Description Qty. Part #
A left screen mount tube 1 009-1281
B right screen mount tube 1 009-1280
C right foot assembly 1 009-1247
D left foot assembly 1 009-1246
E horizontal tube 4 009-1283
F back plate 1 009-1240
G tube cap 2 590-1289
H 1/4'' split washer 42 540-9402
I 1/4" SAE flat washer 42 540-9440
J 1/4-20 x 1/2'' phillips screw 38 510-9108
K M10 screw with lock washer & flat washer 16 520-1041
L adapter bracket 2 009-1284
M M8 x 25 mm phillips screw 16 520-1031
N 5/16'' SAE washer 16 540-9406
O 5/16'' split washer 16 540-9405
P 5" caster 4 600-0026
Q M16 x 30 mm socket head screw 8 520-1346
R 1/2" flat washer 8 540-1005
S 6 mm allen wrench 1 560-9716
T 1/4-20 x 4'' serrated washer hex screw 4 520-2322
Before you start make sure all parts listed are included with your product.
B
K
A
Some parts may not appear exactly as illustrated
