Peerless-AV SP850-V2X2 - Sell Sheet - Manual

Pull-out Pivot Wall Mount
For 26"-65" Flat Panel Displays
The SP850-V2X2 Pull-out Pivot Mount combines the best features of a wall mount and a pivot arm.
In the closed position, the SP850-V2X2 acts as a flat or tilting wall mount. At only 2.73" (69mm) from
the wall, its unique wall plate and built-in cable management neatly hide all components and
cords. Extended, the sturdy arm construction smoothly glides the display out 11.18" from the wall
and allows the flat panel display to pivot up to 45°. This feature not only enables the display to be
positioned for an optimal viewing angle, but it also provides easy access to the back of the display
for hassle-free maintenance. The SP850-V2X2 is also ideal in applications where the display needs
to be recessed into the wall, custom framed or aligned into a multi-display wall.
Perfect for in-wall or
recessed applications
Display size: 26"-65" Max load: 150lb (68kg)
SP850-V2X2
 Built in pivot up to 90° (45°
in each direction) allows for
adjustable viewing angles
 Easy pull-out pivot provides
quick maintenance access
 Dedicated VESA ® 200 x 200
mounting pattern
 2.73" (69mm) deep
when retracted, pivot
arms extend up to 11.18"
(284mm) when extended
 Clean profile design hides
wiring and mount within the
enclosed wall plate
 IncreLok™ tilt provides tilt at
0°, 5° and 10°
 ±1° of roll for horizontal
display leveling during
installation
 Lock Key™ installation tool
secures arms for display
installation
 Lock-out screw prevents
unwanted extension
 Mounts to 16" wood studs,
concrete and cinder block
FeatureS
LockKey™ Installation tool
secures pivot arms in place
Dedicated Models
(SP850 shown)
CLICK: peerless-av.com CaLL: 800.865.2112 FaX: 800.359.6500
eNHaNCeD SeCurItY
Prevent tampering or theft
with unique LockKey™
installation brace and security
screws on the adapter plate
OPtIMuM VIeWING aNGLe
Offers up to 90º of pivot for flexible
display positioning, with 45º each way
CLeaN PrOFILe DeSIGN
Hides cables within
enclosed wall plate for
a clutter-free installation
PuLL-Out SerVICe aCCeSS
Provides easy access to the back
of the display for maintenance
