TOOL-LESS TiLT adjuSTmEnT
Tilt mechanism offers up to +15°/-5°
of tilt angle adjustment without the
use of tools
VESA ® 200mm Articulating Wall Mount
for 22"-37" Flat Panel Displays
Its easy to get the best viewing position when you can effortlessly pull the display out from the
wall, position it in almost any direction, turn it around corners and then smoothly return it to the
wall when finished. The tilt can effortlessly be adjusted without the use of tools and the roll enables
the display to quickly be leveled at any time, even after installation. Never worry about cables
getting in the way; cable management delivers an organized look to any installation.
Display size: 22"-37" Max load: 55lb (25kg)
YBA2X2
 Extends 14.77" (375mm)
from the wall
 Retracts to 3.18" (81mm)
to save space
 Integrated cable
management keeps
cables organized and
out of the way
 Tilt mechanism offers
+15°/-5° of tilt angle
adjustment without the
use of tools
 ±5 ° of roll for post-
installation display leveling
 ±90° of swivel
 VESA ® 100, 200 x 100
and 200 x 200mm compliant
 UL listed
FEaTurES
CLiCK: www.peerless-av.com CaLL: 800.865.2112 FaX: 800.359.6500
ViEwing FLEXibiLiTy
Extends up to 14.77"
(375mm) from the wall
STandardizEd COmpaTibiLiTy
VESA ® 100, 200 x 100 and
200 x 200mm compliant
