Pivot Wall Mount
for 10"-29" Displays
Matching elements of easy installation and user-friendliness are found in this pivot mount. It
boasts a low-profile wall plate design that easily attaches to the wall with only two screws.
The pivot arm extends away from the wall with ease and closes back up to save space. The
arm’s multiple pivot points allow the display to swivel, tilt and roll for the perfect viewing angle
adjustment and display leveling. Its fully integrated cable management system eliminates
unsightly cable clutter and provides a safeguard for the cables. Designed and built in the
USA, this mount maintains the same brilliant look as the entire SmartMount
® 700 Series line of
Articulating and Pivot Wall Arm Mounts.
Display size: 10"-29" Max load: 25lb (11kg)
SP730P
 Compatible with 10"
to 29" displays with
mounting hole patterns of
75 x 75 and 100 x100mm
 Display can be held as
close to the wall as 2.44"
(62mm) or be extended
as far as 9.31" (237mm)
 Pre-tensioned tilt
mechanism offers up to
±35° of One-Touch™ tilt
 ±7° of roll allow for post-
installation leveling
 Display can be swiveled
a full ±45° for obtaining
ideal viewing direction
 Integrated cable
management system
makes running cables
simple while keeping the
cables protected
 UL Listed
FeatureS
Cable management from the
display to the wall plate for
an organized, clean look
Viewing Flexibility
Arm extends up to 9.31"
(237mm) from wall
ideal tilt with
JuSt a touch
One-Touch™ tilt allows
adjustment of ±35°
without the use of tools remarkable Form
Single stud mounting
for a low-profile, fast
installation
Post-installation leveling
click: peerless-av.com call: 800.865.2112 Fax: 800.359.6500
Patented. Design Patent No. D666,180; D631,038; D640,673; D633,484; D634,739; D643,835.
Utility Patent No. 8,028,964 .
