Pivoting Wall Mount
For 10" to 24" Displays
The PP730 pivoting wall mounts feature versatile display positioning and one-person, Hook-
and-Hang™ easy installation. The pivoting arm allows you to extend the display up to 7.13"
(181mm) from the wall, and can retract to just 2.48" (63mm) from the wall. The integrated
cable management provides a clean, professional finish. One-Touch™ tilt of ±15°, ±5° roll for
post-installation leveling, and ±90° pivoting means the display will be perfectly positioned for
the optimum viewing angle.
Display size: 10"-24" Max load: 25lb (11kg)
PP730
 Fits 10" to 24" displays, up to
25lb (11kg)
 Extends display 7.13"
(181mm) from the wall
 Retracts to hold display just
2.48" (63mm) from the wall
 ±90° of pivot allows for
perfect display positioning
 Quick and easy,
Hook-and-Hang™
one-person installation
 Integrated cable
management provides
clean, professional
installation finish
 Easy leveling ±5° after display
installation
 Landscape or portrait
mounting options increases
display versatility
 Mounts to wood studs,
concrete, cinder block or
metal studs (metal stud
accessory required)
 VESA ® 75 and 100mm
compliant
 Installation hardware
included
 UL Listed
 Five-year warranty
FeatureS
CLICK: peerless-av.com CaLL: 800.865.2112 FaX: 800.359.6500
pIvot arm
Allows ±90° of pivot and
7.13" (181mm) of extension
from the wall
Arm extends up to 7.13"
(181mm) and retracts to just
2.48" (63mm) from the wall
KeyhoLe deSIgn
Saves installation time
hooK-and-hang™ SyStem
Offers easy, one-person
installation of the display
one-touCh™ tILt
Offers ±15° of viewing angle
adjustment
±15° of viewing angle
