Peerless-AV DST360 - Sell Sheet - Manual

Flat/Tilt Universal Wall or Ceiling* Mount
with Computer/Media Controller Storage
For 26" to 60" (66 to 152 cm) flat-panel displays
The DST360 offers a “single-box” solution to digital signage and public space flat panel installations.
This versatile solution enables ceiling or wall mounting, it provides plenty of space for a computer or
media box storage and allows access to the media device without having to remove the display.
Designed for ease-of-assembly and security this mount incorporates a step-by-step installation
instructions and includes security option that ensures the display stays in place. Enhancing
effectiveness of the mounted display, this product incorporates a built-in swivel** 360 degrees
that positions the display at the perfect angel for optimal effectiveness.
**Ceiling mount application
Media controller storage
area within mount
MEDIA CONTROLLER HOUSING
Available area within mount for
housing a computer or media
controller device
TV size: 26"-60" (66-152cm) Max load: 150lb (68kg)
DST360
 Ideal for wall or ceiling
mounted applications
 Universal mounting in either
portrait or landscape
orientation
 Built-in swivel up to 360º
allows for optimum viewing
angle for ceiling mount
applications only
 Flat and tilt wall mount
functionality (up to 20º tilt)
 Available area within mount
for housing a computer or
media controller device
15" x 9" x 3" (381 x 229 x 76mm)
 Mount folds open for easy
access to the computer or
media controller without
removing the display
 Access panel opens to a
full 20º for serviceability,
replacement, repair or
maintenance
 Clean profile design hides
wiring and mount within
enclosed wall plate
 Built in adapter plate supports
VESA ® 100 x 100, 200 x 100,
200 x 200 and 300 x 300mm
 Works with all PLP-style VESA ®
mounting hole adapter plates
 Includes hardware for
installation to wood*** and
metal**** studs, concrete or
cinder block
* * Mounts to single stud or 16" stud centers
(wall application)
**** Rated to 150lb (68kg) display max using
dual metal stud, or 60lb (27.22kg) display
max using single metal studs
 Security screws prevent
tampering and theft
FEATURES
UNIVERSAL MOUNTING OPTIONS
Ideal for wall or ceiling installations
SERVICE ACCESSIBILITY
Mount folds open 20° from the
bottom for computer or media
controller service access
without removing the display
CLEAN
APPLICATION
Internal cable
management
delivers a clean,
clutter-free side
profile and
rear view
* Works with any standard EXT, ADD, or ADJ extension columns and ceiling mounts (sold separately)
FLEXIBLE VIEWING
Ceiling mounted:
built-in swivel,
up to 360º, allows
for optimum
viewing angle
Wall mounted:
flat and tilt options
with up to 20º tilt
Ceiling mounted side
view with forward tilt
Built-in ventilation and
cable management
Back view Front view
(display attachment side)
