Peerless-AV LT-320 - Installation - Manual (Page 7)

ISSUED: 06-09-05 SHEET #: 201-9486-2 06-04-07
Visit the Peerless Web Site at www.peerlessmounts.com For customer service call 1-800-729-0307 or 708-865-8870.
7 of 7
Position bottom slots of adapter bracket (A) onto
the two M5 x 10 mm socket screws (H) attached to
mounting bracket (B).
Attach two M5 x 10 mm socket screws (H) through the top holes (use slots as shown for tilt option) on the sides of
mounting bracket (B), and into the threaded inserts of adapter bracket (A). Tighten with the 4mm security allen
wrench (I).
Attaching mounting bracket using tilt option
Attach two M5 x 10 mm socket screws (H) to the
bottom holes on the sides of mounting bracket (B)
using the 4mm security allen wrench (I) provided.
H
B
H
B
A
SLOT
6
6-1
6-3
6-2
H
B
H
A
TOP HOLE
