Ultra Slim Articulating Wall Arm
For 37" to 60" Ultra-thin Flat Panel Displays
*
This slim articulating mount transforms the viewing experience from ordinary to extraordinary.
Ultra-thin displays give the room a contemporary look, but only when married to an ultra-slim
mount that allows the maintenance of the ultra-thin aesthetic and still position the display at the
best viewing angle. Brilliant in its simplicity and ease of installation, the mount’s functionality is
optimized through its remarkable arm extension and swiveling hinge. Now you can create the
perfect viewing angle and truly achieve the ultra-thin experience at the same time.
EffortlEss
motion
One-Touch™ tilt
allows for ideal
viewing angles
with ease from nothing
to EvErything
Arm retracts to only 1.26"
(32mm) and extends up to
24.12" (613mm) from the wall
Display size: 37"-60" Max load: 60lb (27kg)
SUA751H
 Universal mount fits
displays with VESA ®
mounting patterns of
300 x 300 and 400 x 400mm
 Arm retracts to only 1.26"
(32mm) and extends up
to 24.12" (613mm) from
the wall
 +15/-5° of One-Touch™
tilt allows for ideal viewing
angles without the use of
tools
 Up to ±90° of side-to-side
swivel
 ±5° of roll offers a simple
way to horizontally level the
display post-installation
 Double stud wall plate
allows for perfect mount
placement
 Adapter plate’s hourglass
design helps avoid blocking
connections on the back of
the display
 Adapter plate keyhole slots
allow for a quick and easy
single person install
fEaturEs
* Designed exclusively for use with ultra-
thin screens 2” (50.8mm) deep or less
CliCK: peerless-av.com Call: 800.865.2112 faX: 800.359.6500
Flat against the wall Fully extended Improved tilt hinge
