Ultra Slim Articulating Wall Arm
For 32" to 55" Ultra-thin Flat Panel Displays
*
This slim articulating mount transforms the viewing experience from ordinary to extraordinary.
Ultra-thin displays give the room a contemporary look, but only when married to an ultra-slim
mount that allows the maintenance of the ultra-thin aesthetic and still position the display at the
best viewing angle. Brilliant in its simplicity and ease of installation, the mount’s functionality is
optimized through its remarkable arm extension and swiveling hinge. Now you can create the
perfect viewing angle and truly achieve the ultra-thin experience at the same time.
From nothing
to everything
Arm retracts to only 1.29"
(33mm) and extends up to
24.17" (614mm) from the wall
Display size: 32"-55" Max load: 60lb (27.22kg)
SUA746H
 Universal mount fits
displays with VESA ®
mounting hole patterns
of 200 x 200, 300 x 300
and 400 x 400mm
 Arm retracts to only 1.29"
(33mm) and extends up to
24.17" (614mm) from the wall
 +15/-5° of One-Touch™
tilt allows for ideal viewing
angles without the use
of tools
 Up to ±90° of side-to-side
swivel
 ±5° of roll offers a simple
way to horizontally level the
display post-installation
 Two-screw wall attachment
allows for a fast installation
 Adapter plate’s hourglass
design helps avoid blocking
connections on the back of
the display
 Adapter plate keyhole slots
allow for a quick and easy
single person install
FeatureS
Flat against the wall Fully extended
* Designed exclusively for use with ultra-
thin displays 2" (50.8mm) deep or less
CLiCK: peerless-av.com CaLL: 800.865.2112 FaX: 800.359.6500
Improved tilt hinge
eFFortLeSS
motion
One-Touch™ tilt allows
for ideal viewing
angles with ease
