Ultra Slim Tilting Wall Mount
For 37" to 70" Displays
This ultra-slim, universal tilting wall mount holds the display one-inch (25mm) from the wall, giving
a sleek, low-profile finish for today’s ultra-thin flat panel displays. Designed specifically with
the professional installer in mind, this mount offers a quick and easy, one-person installation.
Attachment and detachment of the vertical adaptors with a safety clip and pull cord offers a
secure and quick attachment to the wall plate, without the use of tools. Post-installation height
adjustment, back tilt, and tilt lock at 0° offer maximum functionality.
one-touch™ tilt
Offers ±10° of viewing angle
adjustment
Display size: 37"-70" Max load: 105lb (48kg)
SUT670P
 Fits 37" to 70" displays, up to
105lb (48kg)
 Holds displays only 1"
(25mm) from the wall,
creating a low-profile finish
perfect for today’s ultra-thin
displays
 Quick and easy,
Hook-and-Hang™
one-person installation
 Secure and quick
attachment to the wall
plate, without the use of
tools
 Easy leveling after display
installation
 ±10° of One-Touch™ tilt
for smooth viewing angle
adjustment
 Installation hardware
included
 UL listed
 Five-year warranty
clicK: peerless-av.com cAll: 800.865.2112 FAX: 800.359.6500
FeAtureS
SAFety clip And pull cord
Offers secure attachment to
the wall plate without the use
of tools
Adaptor Extensions
low proFile deSign
Holds display 1" (25mm)
from the wall, for sleek
mounting installation
tilt locK
Holds display securely
against the wall at 0°
Up to 1" (25mm) of
vertical adjustment
Single rAil wAll plAte
Enables quick, one-person
installation
AdAptor eXtenSionS
Attach for larger VESA ®
mounting patterns or
may be removed to
accommodate bump-outs.
Safety clip Low-profile design at 1"
(25 mm) with tilt lock
at 0°
