Universal Tilt Wall Mount
for 10" to 29" Displays
Installations are made quick and easy with this VESA ® compliant mount. Its preassembled
design is fast and easy to install. Simply attach the wall plate to the wall, attach the adaptor
plate to the display and hang the display onto the wall plate. Tilt can be adjusted without
the use of tools to guide the display to the ideal viewing angle.
Low-profile design holds display
only 1.58" (40mm) from the wall
Display size: 10"-29" Max load: 80lb (36kg)
ST630(P)
ST630-AB/AW
 VESA ® 75 and 100mm
compliant
 Additional display adaptor
plates also available
 +15°/-5° tilt adjustment
without the use of tools
 Display adaptor plate
simply hooks onto the wall
plate for quick and easy
installation
 Includes hardware for
installation to wood stud,
concrete, cinder block
and metal stud (metal stud
accessory required)
 UL listed
 Agion ® antimicrobial* finish
assists in controlling the
spread of infections with
ST630-AB/AW models
FeatureS
Quick inStallation
Pre-assembled for fast
and easy installation
eaSY inStallation
Display adaptor plate simply
hooks onto wall plate for
quick and easy installation
Standardized
compatibilitY
VESA ® 75 and 100mm
compliant for reliable
display compatibility
ideal Viewing angle
Tilt adjustment of +15°/-5°
without the use of tools
Nature’s antimicrobial
ST630-AB/AW: * Antimicrobial protection is limited to the treated article and does not protect a user against disease
causing bacteria. Always clean products thoroughly after each use. Visit agion-tech.com for more details.
click: peerless-av.com call: 800.865.2112 FaX: 800.359.6500
Patented. Utility Patent No. 8,517,322; 7,641,163;
7,753,332; 8,313,073; 8,028,964; 8,157,233; 8,282,059.
