7

2013-10-4 #:125-9474-1

D (4)

8mm concrete anchor

E (4)

#14 x 2-1/2" wood screw

M5/M4/M6 washer

N (4)

spacer

M (4)

M5 x 6mm

O (4)

#10 flat washer

P (4)

Q (1)

4mm allen wrench

connection bracket

F (1)

G (4)

M5 x 12 mm

H (4)

M5 x 25 mm

I (4)

M6 x 12 mm

J (4)

M6 x 25 mm

M8 x 12 mm

K (4)

M8 x 25 mm

L (4)
