Peerless-AV LCT620A - Sell Sheet - Manual

Monitor Desktop Arm with Extension
for up to 30" Monitors
The LCT620A monitor mount features a flexible articulating arm and includes a grommet and
desk clamp mount solution. Installation is quick and easy and frees up desk space to allow
positioning of the monitor for greater productivity. Instantly set the height of the monitor into
a comfortable viewing position. A quick release mechanism instantly secures the monitor.
Raise or lower the monitor, extend out, tilt forward and back, pan and rotate for portrait and
landscape viewing.
Display size: up to 30" Max load: 15lb (7kg)
LCT620A
 Two desk assemblies
in one box, the desk
clamp and grommet
are supplied for either
desk mounting solution
 Arm extends and
adjusts for perfect
positioning and
ergonomic comfort to
help reduce eye, back
and neck strain
 Independent tension
adjustment on the arm
 Tilt: +80°/-20°
Pan/Swivel: 180°
Rotate: 360°
 Portrait or landscape
without removing the
monitor
 Compatible with VESA ®
75 and 100mm
 Can be used in laptop
configuration with
ACC329
FeatureS
Cable ManageMent
Cable management clips keep
cables organized and out of the way
ClICK: peerless-av.com Call: 800.865.2112 FaX: 800.359.6500
Desk clamp and
grommet mount option
DeSK aSSeMbly
For wood or composite surfaces
of at least 3" (76mm) thick
Internal cable management Quick release mechanism
360º rotatIon
Arm folds back over the base into
a compact retracted position
QuICK releaSe
MeChanISM
Monitor slides onto
the pedestal and
can be locked into
place in seconds
