In-wall Mount
For 22"-40" Flat Panel Displays
Make the most of your flat panel experience by installing it flat against the wall with Peerless-AV
IM740P In-Wall Articulating Arm. Installation is quick and easy thanks to the mount’s stud-locating
tabs that fit the in-wall box snugly between 16" wood stud centers. View the flat panel display
in its virtually no-profile home position, or extend the arm up to 13.75" to watch it practically
anywhere else within the room. This mount is so flat, it may even allow installations to meet ADA
requirements.
Stud locating tabs
Display size: 22"-40" Max load: 80lb (36kg)
IM740P(-S)
 Installs between 16"
(406mm) wood stud
centers
 Stud-locating tabs adjust
¼" (6mm) left to right
to accommodate stud
spacing
 Includes articulating
mount for 22"-40" displays
 Convenient installation
of power and cables
with removable outlet
receptacle and cable
access plates
 Height adjustment points
in box to set display in
desired position
 VESA ® 75, 100, 200 x
100 and 200 x 200mm
compliant
 Can be inverted to
position display to the
right or the left
FeatureS
Removeable outlet receptacle
SimpliFied inStallation
Stud locating tabs assist
with a quick and easy
installation
power, no problem
Easily install an outlet with
a built-in removable outlet
receptacle
Clean appliCation
Integrated cable
management provides
ample space to run cables
