Peerless-AV SUT645P - Sell Sheet - Manual

Universal Ultra Slim Tilt Wall Mount
For 32" to 46" Ultra-thin Flat Panel Screens
*
The SUT645P Universal Ultra Slim Tilt Wall Mount is the industry’s slimmest tilt wall mount that delivers
an aesthetically-pleasing mounting solution with no sacrifice to functionality. Its innovative design
and use of new technologies merge style with state-of-the-art continuous tilt technology, horizontal
adjustment, and installer-friendly features. Complementing its versatility and functionality is a
sleek, ultra-low profile design with a high gloss black finish that harmonizes the screen with the
mount. The SUT645P provides the ultimate combination of looks and functionality in an ultra-thin
package for the perfect, close-to-the-wall screen installation.
Ideal VIewIng PosItIon
Full tilt motion provides the
perfect viewing angle
Screen size: 32"-46" Max load: 100 lb (45 Kg)
SUT645P
 Holds screen 0.68" (17 mm)
from the wall in the closed
position
 Compatible with ultra-thin
screens with up to VESA ®
600 x 400 mm mounting
hole pattern
 Innovative tilt mechanism
allows for easy setting of the
tilt angle in just one motion
 Tilt range of +17.5°/-5° to
position the screen at the
ideal viewing angle
 Screen can be held off the
wall more than 5.5"
(140 mm) allowing for
hands-free full access to the
back of the screen
 Horizontal adjustment up
to 6" (152 mm) for perfect
screen placement
 Screen adapter simply
hooks onto wall plate for
quick and easy installation
 Lockdown tab prevents
screen from unwanted
bump-off or horizontal
shifting
ClICK: www.peerlessmounts.com Call: 800.865.2112 FaX: 708.865.2941
Features
easY InstallatIon
Simple hook-on design
makes installation quick
and easy
Full motion tilt allows
for +17.5/-5°
Holds screen 0.68"
(17 mm) from the wall
ultra slIm desIgn
The mount virtually
disappears behind
the screen
Screen extended up to
5.88" (149 mm) from the
wall allowing for hands-
free installation access to
the back of the screen
InCreased wall aCCess
Open wall plate architecture
increases cable management
options
* Designed exclusively for use with ultra-
thin screens 2" (51 mm) deep or less
