Outdoor Universal Tilt Wall Mount
for 32" to 55" Flat Panel Displays
Peerless’ Outdoor Universal Wall Mount provides a sure way to mount flat panels outdoors with
its corrosion resistant E-Coat and stainless steel hardware that is resistant to corrosion when
exposed to the elements. In addition to simple installation with its hook-and-hang design, this
mount offers tilt functionality while keeping the flat panel screen a mere 2.58" from the wall.
Tamper-resistant hardware deters theft, offering a peace-of-mind with every installation. For
additional security, lock down channels in the brackets are included for optional padlock
attachment to wall plate.
One-touch tilt adjustment
of +15/-5°
Screen size: 32"-55" Max load: 175lb (79kg)
EPT650
 For Indoor/Outdoor use
where corrosion protection
is needed
 Supports displays with
29.04" W x 17.67" H
(738mm W x 449mm H)
Mounting Pattern and
up to 600 x 400mm
VESA ® compliant
 +15°/-5° tilt with 5° lock
increments
 8" (203mm) of horizontal
screen adjustment
 2.58" (66mm) from the wall
 Double stud mounting
with 16", 20" & 24" stud
placements
 Security hardware
and optional lock down
channels to add a pad
lock additional security
 Wood, concrete or cinder
block mounting hardware
included
CLICK: www.peerlessmounts.com CALL: 800.865.2112 FAX: 708.865.2941
FeAtureS
eASy ACCeSS
Open Wall Plate Design provides
easy access and pass through of
cables to internal and external
power and content sources
eASy SCreen CenterIng
8" (203mm) of horizontal adjustment
for ideal screen position
VIewIng AngLe FLeXIbILIty
Incremental tilt settings enable
the best viewing angle
SImpLe Set-up
Hook-and-hang design helps
attach enclosure to mount
and hold the weight load
while fine-tuning adjustments
