Articulating Wall Arm
For 10"-29" Displays
From any angle, this wall arm mount reflects remarkable form and function. Extending the display
up to 16.06" (408mm) from the wall and allowing for a full 180° of side-to-side motion for viewing
in any part of the room. Fine-tuning of the installation is simple with its side-to-side display leveling
features that help achieve installation perfection. This articulating arm also provides display
centering on the wall plate and integrates a cable management system, centering the TV on the
wall when retracted and organizing and protecting the cables at all times. Designed and built in
the USA, this mount maintains the same brilliant look as the entire SmartMount
® 700 Series line of
Articulating and Pivot Wall Arm Mounts.
Screen size: 10"-29" Max load: 25lb (11kg)
SA730P
 Compatible with 10" to
29" displays with mounting
hole patterns of 75 x 75
and100 x 100mm
 Display can be held as
close to the wall as 2.19"
(56mm) or be extended as
far as 16.06" (408mm)
 Pre-tensioned tilt
mechanism offers up to
±35° of One-Touch™ tilt
 ±7° of roll allow for post
installation leveling
 Multi-arm construction
allows for a full 180° range
of motion
 Display can be swiveled a
full 90°
 Built-in cable management
system makes running
cables simple while
keeping the cables
protected
 Display centers on wall
plate for easy mount
placement
 UL Listed for up to 25lb
(11kg) load capacity
FeatureS
Cable management from display
to wall plate protects and
organizes cables
Viewing Flexibility
Arm extends up to 16.06"
(408mm) from wall
ideal tilt with
JuSt a touch
One-Touch™ tilt allows
adjustment of ±35°
without the use of tools
remarkable Form
Single stud mounting for a
low-profile and fast installation
clean application
Built in cable management
system keeps cables
organized and protected
Post-installation leveling
click: peerless-av.com call: 800.865.2112 Fax: 800.359.6500
Patented. Design Patent No. D666,180; D640,675; D630,197; D634,739; D643,835; D631,038; D631,874.
