J (1), M (2) n (2), L (4) – Peerless-AV IM746P - Installation User Manual

Page 6: Z (1), T (1), W (1), R (4), O (4), P (4), Q (4)

background image

6

2013-02-05 #:095-9406-3 (2013-10-11)

J (1)

wall arm

#14 x 2-1/2" wood screw

M (2)

N (2)

washer

L (4)

M5 x 6mm

cable tie anchor

Z (1)

cable tie

T (1)

8-32 x 1/4"

W (1)

M8 x 20mm

R (4)

M5 x 14mm

O (4)

M6 x 14mm

P (4)

M6 x 30mm

Q (4)

M8 x 30mm

S (4)

small spacer

U (4)

large spacer

V (4)

VESA strip

X (2)

VESA strip

Y (2)

VESA strip washer

I (2)
