JACKRABBIT® SERIES RAMBOX 2
Read the instructions carefully before you start. Due to the custom fi t of this truck bed cover the installation will
require a second person to help in placing the canister in the truck bed. If you have questions regarding the
installation please call our Technical Support Line at (800) 338-3697.
3/8” wrench or socket
#2 Phillips screwdriver
Razor box Knife
TOOLS REQUIRED FOR ASSEMBLY:
BEFORE YOU START:
PACKAGING CONTENTS:
Canister
Rails
(Left &
Right)
Drain Tubes
Hardware kit
Top Cover
Rails Come in a
separate Box.
DO NOT USE A KNIFE TO OPEN THE RAIL BOX.
OPEN THE RAIL BOX ALONG THE LENGTH OF THE BOX AND LIFT RAILS OUT TO AVOID SCRATCHING THE
SURFACE OF THE RAILS ON THE PACKAGE STAPLES.
CAUTION!
Remove the top cover from the canister box and set it aside for later installation.
Remove the canister from the box. Using the 3/8” wrench or socket remove the 2 bolts holding the plywood on the
ends of the canister.
DISCARD PLYWOOD PACKAGING AND BOLTS!
Perform a quick inventory to insure all parts are there. Be sure to check inside the small cardboard box for parts.
STEP 1: REMOVE PLYWOOD & INVENTORY CONTENTS
Drill w/ 3/4” taper drill or step drill bit
Riser bars
(Left & Right)
