Calibration Schedule
To obtain the most accurate results from your gauge, please
follow the calibration schedule pre and post installation:
A. For Everyday Driven Vehicles

Calibrate after installation.

Calibrate again, after 3 months of use.

Calibrate twice a year or every 10,000 miles
(whichever comes first).
B. For Race Vehicles

Calibrate after installation.

Calibrate once per race weekend.
C. Dynamometer Use

Calibrate after installation.

Calibrate every 2-3 days, depending on the amount of
usage.
Functions:
1. Prior to operation, the sensor must warm up for 30 seconds. This
is a mandatory process every time the gauge and sensor are
powered from a cold vehicle start. The LED display will show a
scrolling graphic until the warm up phase is complete.
2. If necessary you may perform a manual calibration by pressing
the button on the controller for 3 seconds, to initialize a controller
/sensor calibration sequence. The LED display on the gauge will
show a [2] until the calibrating process is over.
3. If the LED display on the gauge shows a [3] then there is a sensor
error detected. Check and confirm the connection of the sensor and
wire harness
to and from the controller unit. If the connections are secure and in
place,
press the button on the controller for 8 seconds to reset the controller
to the original factory settings. The LED display will show a [2] and
then a [4].
After this the factory settings are programmed and restored to your
controller. If your display shows a [3] again, your sensor may be
defective.
Remember: If you replace or change your sensor you must follow the schedule as if it were a new installation.
Display: This gauge is equipped with 2 separate AFR display methods:
1. Digital Display Read Out:
This displays range is between 20-10 AFR
accurate with-in 1 decimal place (ex 14.7
AFR).
If the AFR is below 10 or higher than 20 for
more than 3 seconds the digital display will
flash while showing the AFR.
2. Analog LED Color Bar Display
This display range is between 20-10 AFR:

4 - Red LEDs = 20 – 18 AFR

10 - Yellow LEDs = 17.9 – 13 AFR

6 - Green LEDs = 12.9 – 10 AFR
Warranty Notice:
The Oxygen Sensor included with this gauge is not manufactured by GlowShift Gauges, LLC. Therefore it is not covered under warranty.
Additional Installation Information & Material Requirements

GlowShift Gauges Approved Conductor Wires: Successfully installing GlowShift Gauges may require lengths of wire (sizes and quantity
depend on vehicle, gauge type, gauge location and / or sensor location). For correct and proper GlowShift Gauge installation and operation, the
use of 18 Gauge (wire diameter) automotive grade conductor wire with sheathing is recommended for one or more gauges per vehicle. When
installing and routing wires from the engine compartment, to inside the vehicle cabin, always employ the use of a rubber grommet. This will
prevent and deter the stripping of power supply and / or sensor wires that is necessary to deliver vital statistics about your engine to your
GlowShift engine monitoring instruments. Never use wire nuts to fasten or bound vehicle / gauge or sensor wiring. Always use securing crimp
connectors or solder individual wire junctions together for optimum gauge installation and operation.

GlowShift Gauges Approved Installation Accessories: GlowShift Gauges may require the installer or user to provide additional products,
accessories or adapters for the correct installation and operation of a gauge or sensor, as per the GlowShift Installation Instructions. When
installing and routing hoses to or from the engine compartment, to inside the vehicle cabin, always employ the use of a rubber grommet. This
will prevent and deter the stretching or pinching of hoses that is necessary to deliver vital statistics about your engine to your GlowShift engine
monitoring instruments.

GlowShift Gauges Installation Instructions: Installation documents are solely to provide a guide for individuals that are mechanically and
electronically able to install products. If you are unsure about the correct procedure of installation for a product or device, you should consult a
professional mechanic or an Authorized GlowShift Installer.
