AMERICAN CAR CRAFT INSTRUCTION
C5 CORVETTE FRONT NOSE CAP
PART# 033021
patent pending
PARTS INCLUDED:
STAINLESS STEEL NOSE CAP
1-COUNTER SINK BIT
6-BLACK FLAT HEAD SCREWS
1-ADHESIVE PROMOTER PACK
1. Remove the six bolts holding the top of the urethane bumper MAKE NOTE of
where any U-shaped body spacers are placed at this area and remove (set aside)
NOTE: Not all cars will have these. Then remove the body clip nuts just under
the urethane bumper.
2. Mark a dot 1/4 inch in front of the newly exposed holes (towards the front of the
car) in the urethane bumper and drill a 1/8 inch hole thru the bumper at these dots
and down thru the actual bumper tab just underneath.
