American Car Craft Corvette Taillight Trim Rings 4Pc Polished 1997-2004 C5 & Z06 User Manual
Page 2
1. Remove all eight factory screws from the taillights. NOTE: These screws will not be reused.
2. Carefully place each taillight cover into position. Do this slowly so that you do not scratch your paint. (If you feel
more comfortable you can tape the painted area around your taillights using masking tape before installing your
new stainless covers). NOTE: The lamps tend to move, so if you use something smaller in diameter then the
screws like a “small” Phillips screwdriver to align everything and then hold it in place prior to installing the
new screws, it will make getting the screws started properly much easier.
3. Once your cover or covers are in position place two of the replacement screws (provided) thru the white button
sockets (provided) and fasten securely being careful not to over tighten.
4. Snap on chrome screw cap covers (provided).
If any questions occur during installation, please contact American Car Craft at 727-861-1500.
Thank you and enjoy your new purchase!
American Car Craft LLC
18924 Sakera Rd Hudson, FL. 34667
Ph 727.861.1500 Fax 727.861.1520
