American Car Craft Corvette Nose Cap - Front Perforated 1997-2004 C5 & Z06 User Manual
Page 2
4. At this time replace the U-shaped body spacers (if equipped) back to there
original locations allowing the U-shape to go around the newly drilled holes.
5. Using#2 Phillips head screwdriver or screw gun fasten the urethane bumper back
into position using the six stainless flat head screws (provided). BE CAREFUL
NOT TO OVER TIGHTEN.
6. Now that you have created a nice smooth and flush surface for your new front
nose cap to bond to, you need to prep the surface by removing any dirt. First wash
with soap and water then scrub with household isopropyl alcohol. Next apply the
adhesive promoter (provided) to the entire area.
7. Now you are ready to install your new nose cap. First place nose cap in place to
check fit, once you are satisfied remove the red liner from the attachment tape and
reposition. Press firmly to set.
Note: Care must be taken when cleaning your cover. It is a good idea to lightly dust
your cover with a clean soft cloth first in order to prevent any particles from
scratching it. Then wipe (using a new clean soft cloth) with a good quality streak
free glass cleaner.
If any questions occur during installation, please contact American Car Craft at
727-861-1500.
Thank you and enjoy your new purchase.
AMERICAN CAR CRAFT
18924 SAKERA ROAD-HUDSON FLORIDA 34667
Phone # 727-861-1500 Fax # 727-861-1520
