AMERICAN CAR CRAFT INSTRUCTIONS

HHR STAINLESS

RADIATOR COVER/HEADER PLATE /GRILLE FACSIA

PART#423007

PARTS INCLUDED:
___5-Stainless Grille Kit Covers
___2-Small Yellow Plastic Spacers
___2-Stainless 6mm Button Head Bolts
___2- Tight Stainless Washers
___2-Shortened #10 Stainless Pan Head Screws
___3-Adhesive Promoter Packs
___2-Adhesive Promoter Tube
___2-Length of 5/8” Chrome Trim
___1-Length of 3/8 Half Round Chrome Trim
___2-Chrome Decorative Bezels
___4-1” Chrome Bolt Caps
___2-Furry Cookies

Your new multi section grill kit comes to you with a clear protective
liner. Do not remove this liner until you have been instructed to do so.


Your new kit has 5 separate parts that will come together beautifully one
section at a time. In order to install these sections you will be asked to
perform some minor modifications and repositioning of a couple of items.

1. With the hood fully opened temporarily remove the entire front grill and
set it aside.

2. Unbolt the two radiator support brackets with a 10mm socket. NOTE:
These brackets will not be reused.

3. Detach the hood release cable from the radiator support as well as the
electrical harness from the top of the radiator and push these two items
completely and securely under the radiator support.
