gasket. Once you have routed the wires you can now install the fender screws provided.
Make sure not to pinch the wire when installing the screws.
Place the proper inner fender liner in position and hold it just to the top of the painted
fender ridge. NOTE: If you are adding the C5 Fender Lighting Kit you will want to lower
it a little and hold the liner just to the top of the black inner fender. Get acquainted with
the position of the liner and check the overall fit. It may be necessary to make some
minor adjustments by hand so that the liner will follow a nice contour to the inner fender.
Once you are satisfied with the fit and you are clear of its position remove the part and
peel a small portion of the red release liner from the back of the part. Allow the liner to
flap over the top edge a little and then place the part back into position. Firmly hold the
part in place as you slide the red release liner from the back of the part pressing firmly to
set as you go. This will permanently set the part in place.
The top fender cap is a very thin self stick strip designed to sit right on top of the fender
hiding the screws. IMPORTANT! This part must be set completely against the top fender
edge for it to achieve enough clearance for the hood. This part will fit nicely against the
factory rubber seal and must sit nice and tight to this seal. Also it is very IMPORTANT
that you line up the notch in the top cap with the notch in the fender wall. This will insure
that the hood will have adequate clearance when opening and closing. You may want to
try lowering the hood before you permanently attach the cap to insure your location is
correct. Once you are satisfied with the fitment and location peel a small strip of the red
release liner from the back of the top cap and reposition it, holding it firmly in the correct
position peel the red liner as you press the cap to the fender. Once you have successfully
installed all four sections of the fender liner kit peel the protective liner to complete the
installation.
Note: Care must be taken when cleaning your covers. It is a good idea to lightly dust
your covers with a clean soft cloth first in order to prevent any particles from
scratching them. Then wipe (using a new clean soft cloth) with a good quality streak
free glass cleaner.
If any questions occur during installation, please contact American Car Craft at
727-861-1500.
Thank You and Enjoy Your Purchase.
