American Car Craft Mustang Air Box Cover Perforated 2 Pc V8 & GT 5.0 2011-2013 User Manual
Page 2
1. The first thing to do will be to thoroughly scrub clean the top surface of the factory air
tube and filter box to remove any and all road grime and dirt. Then swipe that entire
area with the adhesive promoter provided. This chemical is NOT a cleaner but an
adhesive accelerator and must be used as such in order to achieve a nice strong long
term bond.
2. The next step will be to snap on the cylinder collar to the factory air tube. Simply peel
the red release liner from the inside of the tube and then snap it over. Press along its
length the set the attachment tape. It is important to understand the cover will not
completely contour to the factory tube. That is to say some areas will not attach at all
however the tube will contour pretty nicely leaving you with a nice looking cover
firmly set in place. Remove the protective liner.
3. The next section will also peel and stick in place only with this section you will need to
tweak the shape of the section so that it contours to the factory air box perfectly. The
cover comes to you pre- shaped however you MUST contour the part further by hand
in order to achieve a nice complete bond. Once you have achieved a nice shape simply
peel the red release liner from the back of the part and then carefully set it atop the
box area pressing firmly along its perimeter to set the bond. Peel the protective liner
to finish the installation.
If any questions occur during installation please call American Car Craft at 727-861-1500.
Thank you for your purchase!
