MAX2657/MAX2658
GPS/GNSS Low-Noise Amplifiers
2
_______________________________________________________________________________________
ABSOLUTE MAXIMUM RATINGS
DC ELECTRICAL CHARACTERISTICS
(MAX2657/MAX2658 EV kit. V
CC
= 1.6V to 3.3V, T
A
= -40°C to +85°C, no RF signals are applied. Typical values are at V
CC
= 2.85V
and T
A
= +25°C, unless otherwise noted.) (Note 2)
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.
V
CC
to GND ...........................................................-0.3V to +3.6V
Other Pins to GND .................-0.3V to (+ Operating V
CC
+ 0.3V)
Maximum RF Input Power ...............................................+5dBm
Continuous Power Dissipation (T
A
= +70°C)
6-Bump WLP (derates 10.5mW/°C above +70°C) ........840mW
Maximum Current into RF Input ..........................................10mA
Operating Temperature Range ...........................-40°C to +85°C
Junction Temperature ......................................................+150°C
Storage Temperature Range .............................-65°C to +160°C
Lead Temperature (soldering, 10s)..........Reflow Profile (Note 1)
PARAMETER
CONDITIONS
MIN
TYP
MAX
UNITS
Supply Voltage
1.6
2.85
3.3
V
MAX2657
4.1
SHDN = high
MAX2658
7.7
mA
Supply Current
Shutdown mode, SHDN = low
1
µA
Digital Input Logic-High
1.2
V
Digital Input Logic-Low
0.45
V
Digital Input Current
1
µA
AC ELECTRICAL CHARACTERISTICS
(MAX2657/MAX2658 EV kit. V
CC
= 1.6V to 3.3V, T
A
= -40°C to +85°C, f
RFIN
= 1575.42MHz. Typical values are at V
CC
= 2.85V and
T
A
= +25°C, unless otherwise noted.) (Note 2)
PARAMETER
CONDITIONS
MIN
TYP
MAX
UNITS
RF Frequency
L1 band
1575.42
MHz
MAX2657
19.5
V
CC
= 2.85V
MAX2658
17.7
MAX2657
19.4
Power Gain
V
CC
= 1.6V
MAX2658
17.6
dB
V
CC
= 1.8V
0.8
Noise Figure
V
CC
= 3.3V
0.8
dB
MAX2657
-3.5
In-Band 3rd-Order Input Intercept
Point
(Note 3)
MAX2658
+4.5
dBm
MAX2657
+2.5
Out-of-Band 3rd-Order Input
Intercept Point
(Note 4)
MAX2658
+8
dBm
CAUTION! ESD SENSITIVE DEVICE
Note 1: Refer to Application Note 1891:
Wafer-Level Packaging (WLP) and Its Applications.
