Quad band gsm/gprs module wireless makes smarter
GPRS Multi-slot Class 12
Extended Temperature
Range -45 °C to +85 °C
Highly Compact Size
Embedded Internet Services
Protocols
RoHS Compliant
Serial Port
Multiplexer (GSM0710)
Quectel Enhanced AT
Commands
Quad Band
The M20 is a complete Quad-band GSM/GPRS solution in
a B2B connector type which can be embedded in customer
application, offering the highest reliability and robustness.
Featuring an industry-standard interface, the M20 delivers
GSM/GPRS 850/900/1800/1900MHz performance for
voice, SMS, data, and fax in a small form factor with
extremely low power consumption. With a tiny configuration
of 35mm x 32.5mm x 2.95mm, M20 can fit into almost all
the M2M applications, including VTS, Smart Metering,
Wireless POS, Security, etc.
● Quad - band GSM/GPRS module with a size
of 35mmx32.5mmx2.95mm
● Board-to-board connector suits for customer application
● Embedded powerful Internet service protocols
● Based on mature and field-proven platform, backed
up by our support service, from definition to design
and production
M20
Quad Band GSM/GPRS Module
Wireless makes smarter
