MAX2057
1700MHz to 2500MHz Variable-Gain
Amplifier with Analog Gain Control
2
_______________________________________________________________________________________
ABSOLUTE MAXIMUM RATINGS
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.
V
CC
to GND ...........................................................-0.3V to +5.5V
V
CNTL
to GND (with V
CC
applied) .............................0V to 4.75V
Current into V
CNTL
pin (V
CC
grounded) .............................40mA
All Other Pins to GND.................................-0.3V to (V
CC
+ 0.3V)
RF Input Power (IN, IN_A, ATTN_OUT, OUT_A) ...........+20dBm
RF Input Power (AMP_IN)...............................................+12dBm
θ
JA
(natural convection)...................................................35°C/W
θ
JA
(1m/s airflow) .............................................................31°C/W
θ
JA
(2.5m/s airflow) ..........................................................29°C/W
θ
JC
(junction to exposed paddle) ....................................10°C/W
Operating Temperature Range ...........................-40°C to +85°C
Storage Temperature Range .............................-65°C to +150°C
Junction Temperature ......................................................+150°C
Lead Temperature (soldering, 10s) .................................+300°C
DC ELECTRICAL CHARACTERISTICS
(V
CC
= +4.75V to +5.25V, no RF signals applied, all input and output ports terminated with 50
Ω, T
A
= -40°C to +85°C, unless other-
wise noted. Typical values are at V
CC
= +5.0V, T
A
= +25°C, unless otherwise noted.)
PARAMETER
CONDITIONS
MIN
TYP
MAX
UNITS
Supply Voltage
4.75
5
5.25
V
Supply Current
R1 = 1.2k
Ω, R2 = 2kΩ (Note 1)
180
230
mA
R
SET1
Current
R1 = 1.2k
Ω (Note 1)
1
mA
R
SET2
Current
R1 = 2k
Ω (Note 1)
0.6
mA
Gain-Control Voltage Range
(Note 2)
1.0
4.5
V
Gain-Control Pin Input Resistance
V
CNTL
= 1V to 4.5V
250
500
k
Ω
AC ELECTRICAL CHARACTERISTICS
(Typical Operating Circuit with one attenuator connected, V
CC
= +4.75V to +5.25V, T
A
= -40°C to +85°C, unless otherwise noted.
Typical values are at V
CC
= +5.0V, R1 = 1.2k
Ω, R2 = 2kΩ, P
OUT
= +5dBm, f
IN
= 2100MHz, V
CNTL
= 1V, 50
Ω system impedance,
second attenuator is not connected, T
A
= +25°C, unless otherwise noted.) (Note 3)
PARAMETER
CONDITIONS
MIN
TYP
MAX
UNITS
Frequency Range
1700
2500
MHz
Gain
T
A
= +25°C
13.5
15.5
17.5
dB
V
CNTL
= 1V
+0.9
V
CNTL
= 1.8V
+0.41
V
CNTL
= 2.6V
+0.09
T
A
= +25°C to -40°C
V
CNTL
= 3.5V
-0.16
V
CNTL
= 1V
-1
V
CNTL
= 1.8V
-0.56
V
CNTL
= 2.6V
-0.32
Maximum Gain Variation
T
A
= +25°C to +85°C
V
CNTL
= 3.5V
+0.1
dB
Reverse Isolation
37
dB
Noise Figure
(Note 4)
6
dB
Output 1dB Compression Point
+23.8
dBm
Output 2nd-Order Intercept Point
From maximum gain to 15dB attenuation, measured at f
1
+ f
2
(Note 5)
+64
dBm
Output 3rd-Order Intercept Point
From maximum gain to 15dB attenuation (Note 5)
+37
dBm
