MAX2654/MAX2655/MAX2656
1575MHz/1900MHz Variable-IP3
Low-Noise Amplifiers
2
_______________________________________________________________________________________
ABSOLUTE MAXIMUM RATINGS
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.
V
CC
to GND .............................................................-0.3V to +6V
RF Input Power .................................................................+5dBm
Continuous Power Dissipation (T
A
= +70°C)
6-Pin SC70 (derate 3.1mW/°C above +70°C) ..............245mW
Operating Temperature Range ...........................-40°C to +85°C
Maximum Junction Temperature .....................................+150°C
Storage Temperature.........................................-65°C to +150°C
Lead Temperature (soldering, 10s) .................................+300°C
DC ELECTRICAL CHARACTERISTICS
(V
CC
= +2.7V to +5.5V, R
BIAS
= 511
Ω ±1%, T
A
= -40°C to +85°C. No RF signal applied. RFIN is AC-coupled and terminated to 50
Ω.
RFOUT is unconnected. Typical values are at V
CC
= +3V, T
A
= +25°C, unless otherwise noted.) (Note 1)
PARAMETER
CONDITIONS
MIN
TYP
MAX
UNIT
Supply Voltage
2.7
5.5
V
T
A
= +25°C
5.8
8.2
V
RFOUT
= V
CC
T
A
= -40°C to +85°C
9.2
mA
T
A
= +25°C
0.1
1
Operating Supply Current
(MAX2654 only)
V
RFOUT
= GND
T
A
= -40°C to +85°C
2.1
µA
R
BIAS
= 511
Ω ±1%
8.3
10
R
BIAS
= 698
Ω ±1%
5.9
R
BIAS
= 357
Ω ±1%
10.1
V
RFOUT
= V
CC
T
A
= +25°C
R
BIAS
= 511
Ω ±1%,
T
A
= -40°C to +85°C
11.1
mA
T
A
= +25°C
0.1
1
Operating Supply Current
(MAX2655 only)
V
RFOUT
= GND
T
A
= -40°C to +85°C
2.2
µA
R
BIAS
= 511
Ω ±1%
11.5
15.2
R
BIAS
= 715
Ω ±1%
8.5
V
RFOUT
= GND
T
A
= +25°C
R
BIAS
= 511
Ω ±1%,
T
A
= +85°C
13.6
mA
T
A
= +25°C
12.3
Operating Supply Current
(MAX2656 only)
V
RFOUT
= V
CC
T
A
= +85°C
14.6
mA
Input Logic High at V
RFOUT
(Note 2)
2
V
Input Logic Low at V
RFOUT
(Note 3)
0.6
V
MAX2654/MAX2655
15.6
Input Logic High Current
at V
RFOUT
(Note 4)
MAX2656
71
µA
MAX2654/MAX2655
1
Input Logic Low Current
at V
RFOUT
(Note 5)
MAX2656
-24
µA
