DS1080L

Spread-Spectrum Crystal Multiplier

2

_____________________________________________________________________

ABSOLUTE MAXIMUM RATINGS

RECOMMENDED OPERATING CONDITIONS

(T

A

= -40°C to +125°C)

Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.

Voltage on V

CC

Relative to GND .........................-0.5V to +3.63V

Voltage on Any Lead Relative

to GND ...............-0.5V to (V

CC

+ 0.5V), not to exceed +3.63V

Operating Temperature Range .........................-40°C to +125°C
Storage Temperature Range .............................-55°C to +125°C
Soldering Temperature...................See J-STD-020 Specification

PARAMETER

SYMBOL

CONDITIONS

MIN

TYP

MAX

UNITS

Supply Voltage

V

CC

(Note 1)

3.0

3.6

V

Input Logic 1

V

IH

0.7 x

V

CC

V

CC

+

0.3

V

Input Logic 0

V

IL

GND -

0.3

0.3 x

V

CC

V

Input Logic Float

I

IF

0v < V

IN

< V

CC

(Note 2)

±1

µA

Input Leakage

I

IL

0V < V

IN

< V

CC

(Note 3)

±80

µA

SSO < 67MHz

15

67MHz

≤ SSO < 101MHz

10

SSO Load

C

SSO

101MHz

≤ SSO < 134MHz

7

pF

Crystal or Clock Input
Frequency

f

IN

16.0

33.4

MHz

Crystal ESR

X

ESR

90

Clock Input Duty Cycle

F

INDC

40

60

%

Crystal Parallel Load
Capacitance

C

L

(Note 4)

18

pF

DC ELECTRICAL CHARACTERISTICS

(V

CC

= +3.0V to +3.6V, T

A

= -40°C to +125°C.)

PARAMETER

SYMBOL

CONDITIONS

MIN

TYP

MAX

UNITS

Supply Current

I

CC1

C

SSO

= 15pF, SSO = 16MHz

13

mA

Power-Down Current

I

CCQ

PDN = GND, all input pins floating

200

µA

Output Leakage (SSO)

I

OZ

PDN = GND

-1

+1

µA

Low-Level Output Voltage
(SSO)

V

OL

I

OL

= 4mA

0.4

V

High-Level Output Voltage
(SSO)

V

OH

I

OH

= -4mA

2.4

V

Input Capacitance (X1/X2)

C

IN

(Note 5)

5

pF
