DS1642
11 of 11
DS1642 24-PIN PACKAGE
PKG 24-PIN
DIM. MIN MAX
A IN.
MM
1.270
37.34 0.290
37.85
B IN.
MM
0.675
17.15 0.700
17.78
C IN.
MM
0.315
8.00
0.335
78.51
D IN.
MM
0.075
1.91
0.105
2.67
E IN.
MM
0.015
0.38
0.030
0.76
F IN.
MM
0.140
3.56
0.180
4.57
G IN.
MM
0.090
2.29
0.110
2.79
H IN.
MM
0.590
14.99 0.630
16.00
J IN.
MM
0.010
0.25
0.018
0.45
K IN.
MM
0.015
0.43
0.025
0.58
