HD44780U
2
•
64
×
8-bit character generator RAM

8 character fonts (5
×
8 dot)

4 character fonts (5
×
10 dot)
•
16-common
×
40-segment liquid crystal display driver
•
Programmable duty cycles

1/8 for one line of 5
×
8 dots with cursor

1/11 for one line of 5
×
10 dots with cursor

1/16 for two lines of 5
×
8 dots with cursor
•
Wide range of instruction functions:

Display clear, cursor home, display on/off, cursor on/off, display character blink, cursor shift,
display shift
•
Pin function compatibility with HD44780S
•
Automatic reset circuit that initializes the controller/driver after power on
•
Internal oscillator with external resistors
•
Low power consumption
Ordering Information
Type No. Package CGROM
HD44780UA00FS
HCD44780UA00
HD44780UA00TF FP-80B
Chip
TFP-80F Japanese standard font
HD44780UA02FS
HCD44780UA02
HD44780UA02TF FP-80B
Chip
TFP-80F European standard font
HD44780UBxxFS
HCD44780UBxx
HD44780UBxxTF FP-80B
Chip
TFP-80F Custom font
Note: xx: ROM code No.
