Rainbow Electronics DS1124 - Manual (Page 9)

DS1124
5.0V 8-Bit Programmable
Timing Element
Maxim cannot assume responsibility for use of any circuitry other than circuitry entirely embodied in a Maxim product. No circuit patent licenses are
implied. Maxim reserves the right to change the circuitry and specifications without notice at any time.
Maxim Integrated Products, 120 San Gabriel Drive, Sunnyvale, CA 94086 408-737-7600 _____________________ 9
© 2007 Maxim Integrated Products is a registered trademark of Maxim Integrated Products, Inc.
INL
EXAGGERATED
LINE FIT BETWEEN
MEASURED MAX
AND MIN DELAY
MEASURED DELAY
FOR ALL STEPS
MEASURED t D255
MEASURED t D0
255 128 192 64 0
STEP
DELAY
Figure 5. Integral Nonlinearity
Package Information
For the latest package outline information, go to
www.maxim-ic.com/DallasPackInfo.
