Figure 2. RTC REGISTERS AND ADDRESS MAP

HEX ADDRESS

READ

WRITE

Bit7

Bit6

Bit5

Bit4

Bit3

Bit2

Bit1

Bit0

RANGE

00H

80H

0

10-SEC

SEC

00–59

01H

81H

0

10-MIN

MIN

00–59

P

01–12 + P/A

12

A

02H

82H

0

24

10

10-HR

HOURS

00–23

03H

83H

0

0

0

0

DAY

1–7

04H

84H

0

0

10-DATE

DATE

1–31

05H

85H

0

0

10-MONTH

MONTH

01–12

06H

86H

10 YEAR

YEAR

00–99

ALARM 0

07H

87H

M

10-SEC ALARM

SEC ALARM

00–59

08H

88H

M

10-MIN ALARM

MIN ALARM

00–59

P

12

A

01–12 + P/A

09H

89H

M

24

10

10 HR

HOUR ALARM

00–23

0AH

8AH

M

0

0

0

DAY ALARM

01–07

ALARM 1

0BH

8BH

M

10-SEC ALARM

SEC ALARM

00–59

0CH

8CH

M

10-MIN ALARM

MIN ALARM

00–59

P

12

A

01–12 + P/A

0DH

8DH

M

24

10

10 HR

HOUR ALARM

00–23

0EH

8EH

M

0

0

0

DAY ALARM

01–07

0FH

8FH

CONTROL REGISTER

10H

90H

STATUS REGISTER

11H

91H

TRICKLE CHARGER REGISTER

12–1FH

92–9FH

RESERVED

20–7FH

A0–FFH

96 BYTES USER RAM

00–FF

Note: Range for alarm registers does not include mask’m’ bits.

The DS1305 can be run in either 12-hour or 24-hour mode. Bit 6 of the hours register is defined as the
12- or 24-hour mode select bit. When high, the 12-hour mode is selected. In the 12-hour mode, bit 5 is the
AM/PM bit with logic high being PM. In the 24-hour mode, bit 5 is the second 10-hour bit (20 to 23
hours).

The DS1305 contains two time-of-day alarms. Time-of-day Alarm 0 can be set by writing to registers 87h
to 8Ah. Time-of-day Alarm 1 can be set by writing to registers 8Bh to 8Eh. The alarms can be
programmed (by the INTCN bit of the control register) to operate in two different modes; each alarm can
drive its own separate interrupt output or both alarms can drive a common interrupt output. Bit 7 of each
of the time-of-day alarm registers are mask bits (Table 1). When all of the mask bits are logic 0, a time-
of-day alarm only occurs once per week when the values stored in timekeeping registers 00h to 03h
match the values stored in the time-of-day alarm registers. An alarm is generated every day when bit 7 of
the day alarm register is set to a logic 1. An alarm is generated every hour when bit 7 of the day and hour
alarm registers is set to a logic 1. Similarly, an alarm is generated every minute when bit 7 of the day,
hour, and minute alarm registers is set to a logic 1. When bit 7 of the day, hour, minute, and seconds
alarm registers is set to a logic 1, alarm occurs every second.
