IRFTS9342PbF
8 www.irf.com
TSOP-6 Tape and Reel Information
† Qualification standards can be found at International Rectifier’s web site
http://www.irf.com/product-info/reliability
†† Higher qualification ratings may be available should the user have such requirements.
Please contact your International Rectifier sales representative for further information:
http://www.irf.com/whoto-call/salesrep/
††† Applicable version of JEDEC standard at the time of product release.
IR WORLD HEADQUARTERS: 101 N. Sepulveda Blvd., El Segundo, California 90245, USA Tel: (310) 252-7105
TAC Fax: (310) 252-7903
Visit us at www.irf.com for sales contact information. 02/2012
Data and specifications subject to change without notice.
8mm
FEED DIRECTION 4mm
NOTES :
1. OUTLINE CONFORMS TO EIA-481 & EIA-541.
9.90 ( .390 )
8.40 ( .331 )
178.00
( 7.008 )
MAX.
NOTES:
1. CONTROLLING DIMENSION : MILLIMETER.
2. OUTLINE CONFORMS TO EIA-481 & EIA-541.
MS L1
(per IPC/JE DEC J-S T D-020D ††† )
RoHS compliant Yes
TSOP-6
Qualification information †
Moisture Sensitivity Level
Qualification level
Consumer ††
(per JEDE C JE S D47F ††† guidelines )
