DS1094L
Multiphase Spread-Spectrum EconOscillator
2
_____________________________________________________________________
ABSOLUTE MAXIMUM RATINGS
RECOMMENDED DC OPERATING CONDITIONS
(T
A
= -40°C to +85°C)
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.
Voltage Range on V
CC
, SDA, and SCL
Relative to Ground.............................................-0.5V to +6.0V
Operating Temperature Range ...........................-40°C to +85°C
EEPROM Programming Temperature Range .........0°C to +70°C
Storage Temperature Range .............................-55°C to +125°C
Soldering Temperature .......................................See IPC/JEDEC
J-STD-020A Specification
PARAMETER
SYMBOL
CONDITIONS
MIN
TYP
MAX
UNITS
Supply Voltage
V
CC
(Note 1)
3.0
3.6
V
Input Logic 1 (SDA, SCL)
V
IH
0.7 x
V
CC
V
CC
+
0.3
V
Input Logic 0 (SDA, SCL)
V
IL
-0.3
+0.3 x
V
CC
V
DC ELECTRICAL CHARACTERISTICS
(V
CC
= +3.0 to 3.6V, T
A
= -40°C to +85°C, unless otherwise noted.)
PARAMETER
SYMBOL
CONDITIONS
MIN
TYP
MAX
UNITS
Active Supply Current
I
CC
C
L
= 15pF per output, SDA = SCL = V
CC
1.4
3
mA
High-Level Output Voltage
(OUT1-4)
V
OH
I
OH
= -4mA; V
CC
= min
2.4
V
Low-Level Output Voltage
(OUT1-4)
V
OL
I
OL
= 3.5mA
0.4
V
3mA sink current
0.4
Low-Level Output Voltage (SDA)
V
OL
6mA sink current
0.6
V
High-Level Input Current
(SDA, SCL)
I
IH
V
IH
= V
CC
+1.0
µA
Low-Level Input Current
(SDA, SCL)
I
IL
V
IL
= 0.0V
-1.0
µA
