DS14285/DS14287
23 of 25
DS14285 24-PIN DIP
PKG 24-PIN
DIM MIN MAX
A IN.
MM
1.245
31.62 1.270
32.25
B IN.
MM
0.530
13.46 0.550
13.97
C IN.
MM
0.140
3.56
0.160
4.06
D IN.
MM
0.600
15.24 0.625
15.88
E IN.
MM
0.015
0.380 0.050
1.27
F IN.
MM
0.120
3.05
0.145
3.68
G IN.
MM
0.090
2.29
0.110
2.79
H IN.
MM
0.625
15.88 0.675
17.15
J IN.
MM
0.008
0.20
0.012
0.30
K IN.
MM
0.015
0.38
0.022
0.56
DS14285 24-PIN SOIC
PKG 24-PIN
DIM MIN MAX
A IN.
MM
0.602
15.29 0.612
15.54
B IN.
MM
0.290
7.37
0.300
7.65
C IN.
MM
0.089
2.26
0.095
2.41
E IN.
MM
0.004
0.102 0.012
0.30
F IN.
MM
0.094
2.38
0.105
2.68
G IN.
MM
0.050 BSC
1.27 BSC
H IN.
MM
0.398
10.11 0.416
10.57
J IN.
MM
0.009
0.229 0.013
0.33
K IN.
MM
0.013
0.33
0.019
0.48
L IN.
MM
0.016
0.406 0.040
1.02
phi 0
°
8
°
