DS14285/DS14287

10 of 25

CONTROL REGISTERS

The DS14285/DS14287 has four control registers which are accessible at all times, even during the
update cycle.

REGISTER A

MSB

LSB

BIT 7

BIT 6

BIT 5

BIT 4

BIT 3

BIT 2

BIT 1

BIT 0

UIP

DV2

DV1

DV0

RS3

RS2

RS1

RS0

UIP - The Update In Progress (UIP) bit is a status flag that can be monitored. When the UIP bit is a 1, the
update transfer will soon occur. When UIP is a 0, the update transfer will not occur for at least 244

µ

s.

The time, calendar, and alarm information in RAM is fully available for access when the UIP bit is 0. The

UIP bit is read-only and is not affected by

RESET

. Writing the SET bit in Register B to a 1 inhibits any

update transfer and clears the UIP status bit.

DV0, DV1, DV2 - These 3 bits are used to turn the oscillator on or off and to reset the countdown chain.
A pattern of 010 is the only combination of bits that will turn the oscillator on and allow the RTC to keep
time. A pattern of 11X will enable the oscillator but holds the countdown chain in reset. The next update
will occur at 500 ms after a pattern of 010 is written to DV0, DV1, and DV2.

RS3, RS2, RS1, RS0 - These four rate-selection bits select one of the 13 taps on the 15-stage divider or
disable the divider output. The tap selected can be used to generate an output square wave (SQW pin)
and/or a periodic interrupt. The user can do one of the following:

1. Enable the interrupt with the PIE bit;
2. Enable the SQW output pin with the SQWE bit;
3. Enable both at the same time and the same rate; or
4. Enable neither.

Table 2 lists the periodic interrupt rates and the square wave frequencies that can be chosen with the RS

bits. These 4 read/write bits are not affected by

RESET

.
