Integrated Circuits Inc. aP89021/010
Ver 2.0 Dec 6, 2006 15
OSCILLATOR RESISTANCE TABLE
Sampling Frequency R
OSC
R
OSC
Sampling Frequency
KHz KOhm KOhm KHz
4.90 300 140 11.00
5.26 290 130 11.76
5.88 280 120 12.50
6.09 270 110 13.33
6.33 260 100 14.51
6.67 250 91 15.63
6.85 240 82 16.95
7.14 230 75 18.18
7.46 220 68 19.23
7.70 210 62 20.83
8.06 200 56 22.22
8.47 190 51 23.81
8.93 180 43 25.00
9.26 170
9.80 160
10.42 150
Note: The data in the above tables are within 3% accuracy and measured at V
DD
= 3.0V. Oscillator frequency is
subjected to IC lot to lot variation.
