Integrated Circuits Inc. aP89021/010
Ver 2.0 Dec 6, 2006 13
DC CHARACTERISTICS
( T
A
= 0 to 70℃, VDD = 3.3V, VSS = 0V )
Symbol Parameter Min. Typ. Max. Unit Condition
VDD Operating Voltage 2.2 3.0 3.6 V
ISB Standby current

1 5 μA I/O open
IOP Operating current
 
15 mA I/O open
VIH "H" Input Voltage 2.5 3.0 3.5 V VDD=3.0V
VIL "L" Input Voltage -0.3 0 0.5 V VDD=3.0V
IOL V
OUT
low O/P Current

120

mA Vout=0.3V, VDD=3.0V
IOH V
OUT
high O/P Current

-120

mA Vout=2.5V, VDD=3.0V
ICO C
OUT
O/P Current

-3

mA VCOUT=1.0V, VDD=3.0V
IOH O/P high Current

-8

mA VOH=2.5V, VDD=3.0V
IOL O/P low Current

8

mA VOL=0.3V, VDD=3.0V
∆
F/F Frequency Stability -5
 +5 % Fosc(3V)
Fosc(3.4V) - Fosc(2.7V)
