MAX1044/ICL7660
Switched-Capacitor Voltage Converters
__________________________________________________________Chip Topographies
GND
CAP-
LV
V OUT
TRANSISTOR COUNT: 71
SUBSTRATE CONNECTED TO V+
CAP+
0.084"
(2.1mm)
0.060"
(1.5mm)
V+
OSC
ICL7660
GND CAP+ BOOST
0.076"
(1.930mm)
0.076"
(1.930mm)
CAP-
V
OUT
V+
OSC LV
TRANSISTOR COUNT: 72
SUBSTRATE CONNECTED TO V+
MAX1044
L
α C
A1 B
DIM
A
A1
B
C
D
E
e
H
L
α
MIN
0.036
0.004
0.010
0.005
0.116
0.116
0.188
0.016
0°
MAX
0.044
0.008
0.014
0.007
0.120
0.120
0.198
0.026
6°
MIN
0.91
0.10
0.25
0.13
2.95
2.95
4.78
0.41
0°
MAX
1.11
0.20
0.36
0.18
3.05
3.05
5.03
0.66
6°
INCHES MILLIMETERS
8-PIN
µ
MAX
PACKAGE
0.65 0.0256
21-0036
A
e
E H
D
0.127mm
0.004 in
________________________________________________________Package Information
