Paralleling Devices
Paralleling multiple MAX1044/ICL7660s reduces output
resistance and increases current capability. As illus-
trated in Figure 13, each device requires its own pump
capacitor C1, but the reservoir capacitor C2 serves all
devices. The equation for calculating output resistance is:
Shutdown Schemes
Figures 14a–14c illustrate three ways of adding shut-
down capability to the MAX1044/ICL7660. When using
these circuits, be aware that the additional capacitive
loading on the OSC pin will reduce the oscillator fre-
quency. The first circuit has the least loading on the
OSC pin and has the added advantage of controlling
shutdown with a high or low logic level, depending on
the orientation of the switching diode.
