MAX5510/MAX5511
+1.8V to +5.5V, Ultra-Low-Power, 8-Bit,
Voltage-Output DACs
_______________________________________________________________________________________
5
PARAMETER
SYMBOL
CONDITIONS
MIN
TYP
MAX
UNITS
TIMING CHARACTERISTICS (V
DD
= 4.5V TO 5.5V)
Serial Clock Frequency
f
SCLK
0
16.7
MHz
DIN to SCLK Rise Setup Time
t
DS
15
ns
DIN to SCLK Rise Hold Time
t
DH
0
ns
SCLK Pulse-Width High
t
CH
24
ns
SCLK Pulse-Width Low
t
CL
24
ns
CS Pulse-Width High
t
CSW
100
ns
SCLK Rise to CS Rise Hold Time
t
CSH
0
ns
CS Fall to SCLK Rise Setup Time
t
CSS
20
ns
SCLK Fall to CS Fall Setup
t
CSO
0
ns
CS Rise to SCK Rise Hold Time
t
CS1
20
ns
TIMING CHARACTERISTICS
(V
DD
= +4.5V to +5.5V, T
A
= T
MIN
to T
MAX
, unless otherwise noted. Typical values are at T
A
= +25°C.)
TIMING CHARACTERISTICS
(V
DD
= +1.8V to +5.5V, T
A
= T
MIN
to T
MAX
, unless otherwise noted. Typical values are at T
A
= +25°C.)
Note 1: Linearity is tested within codes 6 to 255.
Note 2: Offset is tested at code 6.
Note 3: Gain is tested at code 250. FB is connected to OUT.
Note 4: Guaranteed by design. Not production tested.
Note 5: V
DD
must be a minimum of 1.8V.
Note 6: Outputs can be shorted to V
DD
or GND indefinitely, provided that the package power dissipation is not exceeded.
Note 7: Optimal noise performance is at 2nF load capacitance.
Note 8: Thermal hysteresis is defined as the change in the initial +25°C output voltage after cycling the device from T
MAX
to T
MIN
.
Note 9: All digital inputs at V
DD
or GND.
Note 10: Load = 10kΩ in parallel with 100pF, V
DD
= 5V, V
REF
= 4.096V (MAX5510) or V
REF
= 3.9V (MAX5511).
PARAMETER
SYMBOL
CONDITIONS
MIN
TYP
MAX
UNITS
TIMING CHARACTERISTICS (V
DD
= 1.8V TO 5.5V)
Serial Clock Frequency
f
SCLK
0
10
MHz
DIN to SCLK Rise Setup Time
t
DS
24
ns
DIN to SCLK Rise Hold Time
t
DH
0
ns
SCLK Pulse-Width High
t
CH
40
ns
SCLK Pulse-Width Low
t
CL
40
ns
CS Pulse-Width High
t
CSW
150
ns
SCLK Rise to CS Rise Hold Time
t
CSH
0
ns
CS Fall to SCLK Rise Setup Time
t
CSS
30
ns
SCLK Fall to CS Fall Setup
t
CSO
0
ns
CS Rise to SCK Rise Hold Time
t
CS1
30
ns
