MAX5889
12-Bit, 600Msps, High-Dynamic-Performance
DAC with LVDS Inputs
_______________________________________________________________________________________ 3
ELECTRICAL CHARACTERISTICS (continued)
(AV DD3.3 = DV DD3.3 = AV CLK = +3.3V, AV DD1.8 = DV DD1.8 = +1.8V, external reference V REFIO = +1.2V, output load 50 Ω double-ter-
minated, transformer-coupled output, I OUT = 20mA, T A = -40°C to +85°C, unless otherwise noted. Specifications at T A
≥ +25°C are
guaranteed by production testing. Specifications at T A < +25°C are guaranteed by design and characterization. Typical values are at
T A = +25°C.)
PARAMETER SYMBOL CONDITIONS MIN TYP MAX UNITS
f OUT = 16MHz 86 f CLK = 200MHz,
0dBFS f
OUT
= 30MHz 85
f OUT = 16MHz 78 f CLK = 200MHz,
-12dBFS f OUT = 30MHz 77
f OUT = 16MHz 77 83
f OUT = 30MHz 79
f OUT = 130MHz 67
Spurious-Free
Dynamic Range to
Nyquist
SFDR
f CLK = 500MHz,
0dBFS
f OUT = 200MHz 63
dBc
f CLK = 500MHz
f OUT1 = 29MHz,
f OUT2 = 30MHz,
-6.5dBFS per tone
-93
Two-Tone IMD TTIMD
f CLK = 500MHz
f OUT1 = 129MHz,
f OUT2 = 130MHz,
-6.5dBFS per tone
-76
dBc
f CLK = 491.52MHz,
f OUT = 30.72MHz
80
WCDMA single
carrier
f CLK = 491.52MHz,
f OUT = 122.88MHz
72
f CLK = 491.52MHz,
f OUT = 30.72MHz
72
Adjacent Channel
Leakage Power Ratio
ACLR
WCDMA four carriers
f CLK = 491.52MHz,
f
OUT
= 122.88MHz
67
dB
Output Bandwidth BW -1dB (Note 2) 1000 MHz
REFERENCE
Internal Reference Voltage Range V REFIO 1.14 1.2 1.26 V
Reference Input Voltage Range V REFIOCR Using external reference 0.10 1.2 1.32 V
Reference Input Resistance R REFIO 10 k Ω
Reference Voltage Temperature
Drift
TCO REF
±30 ppm/ °C
